Performance data sourced from the 70°F ambient curve on the product spec sheet. Dashed segments are linear estimates beyond the published datapoints. Contact our engineering team for performance at your exact operating conditions.
K2L SeriesDeep Freeze 10 Ton Chiller
Model: K2L10-LT-480/3
Air cooled stand-alone 10 ton low temperature chiller designed for indoor operation. Capacity is 63,700 BTU's/hr at rated conditions (120,000 BTU's/hr nominal). Set up for ambient temperatures 35°F to 100°F. Heavy-duty construction built in the United States with the fastest lead times.
Voltage / Phase
FLA: 28.1 A|Recommended breaker: 32.8 A
Capacity
10 Ton
Temp Range
-20°F to 70°F
BTU
63,700 BTU/hr @ 27.5°F / 70°F
Voltage
480V / 3Φ
Key Features
Specifications
Pricing for the Deep Freeze 10 Ton Chiller
Pricing for this unit depends on two things: the tonnage (which you've already selected at 10 Ton) and the voltage configuration you need.
Three-phase 480V is typically the most cost-effective option for facilities that have it available — it allows smaller, more efficient electrical components than 208–240V three-phase configurations.
Ordering Guide
All voltage variants share the same 63,700 BTU/hr @ 27.5°F / 70°F cooling capacity and -20°F to 70°F fluid range. Choose the configuration that matches your facility's available power.
| Part Number | Voltage | Phase | FLA | Breaker | Stock |
|---|---|---|---|---|---|
| K2L10-LT-240/3 | 208-240V | 3Φ | 49.1 A | 68 A | — |
| K2L10-LT-480/3 | 480V | 3Φ | 28.1 A | 32.8 A | — |
| K2L10-LT-575/3 | 575V | 3Φ | — | — | — |
Need Different Specs?
These are our in-stock units — but we design and build custom chillers every day. Different capacity, temperature range, voltage, refrigerant, or footprint? Our engineering team can make it happen.
Don't Forget the Glycol
All North Slope chillers require propylene glycol to operate. If you don't already have glycol on hand, we carry a 50/50 premixed solution that's ready to pour — no mixing required.
Common Applications
What Customers Say About This Product
"Working flawlessly... As a matter of fact, the customer has requested 3 additional on the next project."
Program Manager, Leidos
