A Crash Course on High-Quality CBD Extraction

Increased research on the potential benefits of cannabidiols (CBD and THC) extracted from cannabis plants has led to growing popularity in CBD and THC oils. These high-value extracts require careful extraction methods to go from cannabis plant to oil. Here are a few of the most common CBD and THC extraction methods.

DOWNLOAD OUR COMPLETE CBD GUIDE

CBD vs. THC- What’s the Difference?

THC and CBD are the two main cannabinoids extracted from cannabis plants. Marijuana has a higher percentage of THC while hemp has a higher percentage of CBD. Put simply, THC has the psychoactive properties associated with getting “high” while CBD is said to have more calming, medicinal properties.

Common Extraction Methods

Solvent Extraction

This simple extraction method works by using ethanol as a solvent to remove extracts from cannabis plant trimmings. It usually looks something like this:

1. Ethanol is added to trimmings and mixed for a couple of minutes to allow the ethanol to dissolve extracts from the plant materials.
2. The ethanol is strained from the trimmings.
3. The ethanol/extract mixture is slowly heated until all ethanol evaporates and only the plant extracts remain.

Solvent Extraction Pros:

• Inexpensive- This method doesn’t require any fancy machinery.
• Simple- This method is pretty straightforward and can even be done at home.

Solvent Extraction Cons:

• Dangerous- Ethanol is extremely flammable.
• Could Damage CBD/ THC- Ethanol could potentially denature the CBD or THC if overheated or overmixed.

CO2 Extraction

The CO2 Extraction method uses supercritical carbon dioxide to pull phytochemicals from cannabis plants. Supercritical materials are not quite a liquid but not quite a gas and possess the properties of both. This state is ideal for plant extraction because supercritical CO2 can move through materials like gas and dissolve materials like a liquid.

CO2  extraction typically follows these steps:

1. The CO2 is prepared in a compression chamber. First, CO2  gas is turned into a liquid; this is done by dropping the temperature to under -69°F and increasing the pressure to over 75 psi. Next, the the temperature and pressure are both raised until the liquid becomes supercritical.
2. The supercritical CO2 passes through cannabis trimmings in an extraction chamber where it dissolves and collects extracts from the plants.
3. The CO2 / extract solution then enters a lower-pressure separator chamber. The lower pressure causes the CO2  and plant extracts to separate. The CO2 returns to the CO2 chamber and the cannabis oil is drained from the separator.

CO2  Extraction Pros:

• Safe when done by professionals- CO2 is used in countless food products and is perfectly safe for consumption
• Yields high-quality CBD- machines leave very little room for error

CO2  Extraction Cons:

• Very expensive- setup costs start at approximately $40,000
• Not for novice chemists- it’s best to leave this method to the professionals

Ice Water Extraction

Ice water extraction creates a powdery resin extract often referred to as “hash” or “bubble hash.” There are several variations to this method, but they all follow these general steps:

1. Finely-chopped plant trimmings are mixed with either ice or dry ice.  This step is supposed to help separate extracts from the plant material.
2. Water is added to the ice and trimmings and the entire mixture is strained through a mesh bag. (Often, the mixture is strained multiple times through progressively smaller-micron mesh bags until the purest-possible extracts are obtained)
3. The extracts settle at  the bottom of the strained mixture. The excess water is drained from the top and the extracts are left to dry until they become powdery.

Ice Water Extraction Pros:

• Inexpensive- Again, no fancy machinery needed!
• High Yield- If done correctly, this method produces a relatively large amount of plant extract.

Ice Water Extraction Cons:

• Not always practical- This method can be labor intensive and time consuming.

Temperature Control During Extraction

Regardless of the method used, careful temperature is control is an important element of high-quality yield in CBD and THC extraction. Extreme temperatures damage cannabinoids. Additionally, many processes need specific, extreme temperatures to be effective; if ideal temperatures are not maintained, the extraction process could completely flop. North Slope Chillers’ extraction chillers offer precise temperature control at sub-zero temperatures. Give us a call at
(866) 826-2993 and we’d be happy to tell you more about our products.
